T5 Touch Screen Thermostat
From: £42.99 Inc. VAT
£35.83 Ex. VAT
T5 Touch Screen Thermostat
Programmable with White LCD Display
The T5 Touch Screen Thermostat is designed to operate all standard electric underfloor heating systems.
Combining modern design with intuitive functionality, the T5 offers reliable and stylish temperature control for any room.
Featuring a large, responsive, low-profile white LCD screen and a micro bevel-edged fascia, this thermostat is both visually striking and easy to use.
Its clear on-screen layout makes programming simple, allowing your heating to automatically adjust to suit your daily routine.
The T5 also allows manual temperature adjustment at the touch of a button, giving you instant control whenever needed. Supplied with both an inbuilt air sensor and external floor sensor probe, it ensures accurate and efficient temperature regulation.
For added peace of mind, the T5 Touch Screen Thermostat is supplied with a 1-year manufacturer’s warranty.
What You Need to Know – Technical Overview
The thermostat supports heating loads of up to 16 amps (3600 watts). For larger heating areas or higher loads, additional switching or relaysmay be required.
Alternatively, systems can be split into multiple zones using additional thermostats.
The thermostat must be powered from a dedicated supply from the main consumer unit and installed with suitable electrical protection, such as an RCD or fused spur, by a qualified electrician.
Free Technical Support
All Living Heat thermostats are supplied with full wiring diagrams and clear fitting instructions.
If you require any further assistance or advice, our experienced technical support team is always happy to help.
Features & Technical Specifications
| T5 Thermostat Specifications | |
|---|---|
| Easy to Use & Program | White LCD Display |
| Full Fitting Instructions & Free Phone Helpline | Floor Temperature Sensor |
| Low-Profile Design | Fits 35mm or Deeper Single-Gang Back Box |
| 1-Year Manufacturer’s Warranty | Supply Voltage: 230 / 240V |
| 16 Amp / 3600 Watt Maximum Load | Temperature Range: 5°C – 50°C |
| Extendable Floor Probe (3–15m) | Responsive Touch Screen |
| Ultra-Flat White LCD Screen | Weekday & Weekend Programming |
Free Underfloor Heating Design Service
Living Heat offers a free underfloor heating design service to make the installation process simple and stress-free. For a free quote or further information, please contact us on 01803 316131.
Our time and advice are always free, and we are happy to recommend the most suitable underfloor heating system for your project.
Product Reviews
Technical Information
T5 Touch Screen Thermostat
Technical Data Sheet
The T5 Touch Screen Thermostat is a stylish and intuitive control solution for electric underfloor heating systems.
Featuring a sleek white LCD display and responsive touch screen, it offers full programmable control with the flexibility of manual temperature adjustment at the touch of a button.
Once programmed, the T5 can automate your heating to suit your lifestyle, delivering comfort, efficiency, and ease of use.
Product Information
Product Type:
Touch Screen Digital Thermostat
Application:
Electric Underfloor Heating Systems
Control Mode:
Fully Programmable with Manual Override
Display Type:
Ultra-Flat White LCD Touch Screen
Power Supply:
230 / 240V AC
Maximum Switching Load:
16 Amps (3600 Watts)
Temperature Control
Temperature Adjustment Range:
5°C to 50°C
Temperature Sensors:
Built-in Air Sensor and External Floor Sensor
Floor Sensor Length:
3m (Extendable up to 15m)
Programming Options:
Separate Weekday and Weekend Settings
Installation & Construction
Installation Method:
Flush Mounted
Back Box Requirement:
Single Gang – Minimum 35mm Depth
Design:
Low-Profile, Micro Bevel-Edged Fascia
Protection Rating:
IP20 – Indoor Use Only
Output Type:
Relay Switching
User Interface
Operation:
Responsive Touch Screen Control
Display:
Clear White LCD for Easy Viewing
Manual Adjustment:
Instant Temperature Changes at the Touch of a Button
Compatibility
Suitable Heating Systems:
Electric Heating Mats
Electric Heating Cables
Foil Heating Systems
Compliance & Warranty
Compliance:
CE Marked
Warranty:
1-Year Manufacturer’s Warranty
Installation Notes
The T5 thermostat must be installed by a qualified electrician in accordance with current wiring regulations.
A dedicated power supply from the consumer unit is required, with suitable electrical protection such as an RCD or fused spur.
For loads exceeding 16 amps or larger heated areas, additional contactors or zoning with multiple thermostats may be required.
Technical Support & Design Service
All Living Heat thermostats are supplied with full wiring diagrams and fitting instructions.
Free technical support is available should you require assistance.
Living Heat also offers a free underfloor heating design service.
For a free quote or expert advice, contact us on 01803 316131.
